Q-Tech TCXO用于軍事國防航空電子QTCT236,QTCT570,QT3073C
發(fā)布于：2025-06-12 13:59:28
品牌名稱：Q-TECH
重要參數(shù)：
電壓范圍：2.5-5V
邏輯類型:Clipped Sine、CMOS、LVDS、LVPECL、HCMOS、SINE
封裝類型：DIP-8、SMD
頻率穩(wěn)定性：±0.5 ppm 到 ±2.5 ppm，±1 ppm 到 ±3 ppm
| 型號 | 尺寸 （mm） | 電源電壓 | 封裝類型 | 穩(wěn)定性 | 相位噪聲基底 |
| QTCT220 | 2.0 x 2.5 x 0.7 | 2.8 to 3.3Vdc | Surface Mount (Miniature SMD) 2.0 x 2.5mm 4 Pad | ±0.5ppm to ±2.5ppm | Contact Q-Tech |
| QTCT230 | 2.5 x 3.2 x 0.9 | 2.8 to 3.3Vdc | Surface Mount (Miniature SMD) 2.5 x 3.2mm 4 Pad | ±0.5ppm to ±2.5ppm | Contact Q-Tech |
| QTCT236 | 2.5 x 3.2 x 1.6 | 2.5 or 3.3Vdc | Surface Mount (Miniature SMD) 2.5 x 3.2mm 6 Pad | ±0.5ppm to ±2.5ppm | Contact Q-Tech |
| QTCT350 | 3.20 x 5.00 x 1.10 | 2.8 to 5.0Vdc | Surface Mount (Miniature SMD) 3.2 x 5mm 4 Pads | ±0.5ppm to ±2.5ppm | Contact Q-Tech |
| QTCT570 | 5.00 x 7.00 x 1.90 | 2.8 to 3.3Vdc | Surface Mount (Miniature SMD) 5 x 7mm 4 Pads | ±0.5ppm to ±2.5ppm | Contact Q-Tech |
| QT3073S, QS3073S | 20.7 x 13.06 x 7.50 | 3.3 to 5Vdc | Dual In-line (DIP-8) 4 Pin | ±1ppm to ±3ppm | -155 dBc/Hz @ 80MHz |
| QT3083C, QS3083C | 20.7 x 13.06 x 8.79 | 3.3 to 5Vdc | Surface Mount (SMD) 4 Pads | ±1ppm to ±3ppm | -155 dBc/Hz @ 80MHz |
| QT3093S, QS3093S | 20.7 x 13.06 x 9.78 | 3.3 to 5Vdc | Surface Mount (SMD) Gull Wing 4 Pin | ±1ppm to ±3ppm | -155 dBc/Hz @ 80MHz |
